| Hardware specifications | |
| Radio | Dual-stream dual-band |
| Protocol | Concurrent 802.11b/g/n/ac |
| Operating Bands | 802.11b/g/n ：2.4G ~ 2.4835GHz |
| 802.11a/n/ac ： 5G：5.150～5.350GHz，5.47～5.725，5.725～5.850GHz | |
| (Note: The operating bands vary according to different countries) | |
| Antenna | PCB antenna |
| Spatial Streams | 2.4G: 2 Spatial Streams,2x2 MIMO |
| 5G: 2 Spatial Streams,2x2 MIMO | |
| Max Throughput | 2.4G: up to 400Mbps |
| 5G: up to 866.7Mbps | |
| Modulation | OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps |
| DSSS: DBPSK@1Mbps, DQPSK@2Mbps, and CCK@5.5/11Mbps | |
| MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM and 256QAM | |
| Receive Sensitivity | 11b：-97dBm(1Mbps) ，-92dBm(5Mbps) ，-89dBm(11Mbps) |
| 11a/g：-94dBm（6Mbps），-85dBm（24Mbps），-82dBm（36Mbps），-76.5dBm（54Mbps） | |
| 11n：-93.5dBm@MCS0，-74dBm@MCS7，-74dBm@MCS15 | |
| 11ac：HT20：-92.5dBm（MCS0）, -68.5dBm（MCS8） | |
| 11ac：HT40：-89dBm（MCS0）, -64dBm（MCS9） | |
| 11ac：HT80：-86dBm（MCS0）, -60.5dBm（MCS8） | |
| Maximum Transmit Power | 20dBm (adjustable) |
| Adjustable Power | 1dBm |
| Dimensions | 86*86*29.3 |
| Weight | <0.25kg |
| Service Ports | Front： |
| 1 10/100Mbps Ethernet port | |
| Rear： | |
| 1 10/100Mbps PoE Ethernet port | |
| LED Indicator | Support |
| Power Supply | Support 802.3af power supply |
| Power Consumption | ＜8W |
| Environment | Operating temperature: 0°C～40°C |
| Storage temperature: -40°C～70°C | |
| Operating humidity: 5％～95％（non-condensing） | |
| Storage humidity: 5％～95％（non-condensing） | |
| Installation | 86mm wall plate installation |
| IP Rating | IP41 |
| Safety Standard | GB4943, IEC 60950-1 |
| EMC Standard | GB9254，EN301 489，EN50155，EN50121，EN55032，EN61000，EN55035 |
| Vibration Standard | IEC61373 |
| Radio Standard | SRRC certification |
| Software Features | |
| Operating Mode | AP mode and routing mode |
| WLAN | Maximum number of clients: 110 |
| Recommended number of clients: 24 (8 at 2.4GHz, 16 at 5GHz) | |
| Up to 8 SSIDs | |
| Support SSID hiding | |
| Configuring the authentication mode, encryption mechanism, and VLAN attributes for each SSID | |
| SSID-based and radio-based STA limit | |
| Support Layer 2 user isolation | |
| Roaming | Support Layer 2 and Layer 3 roaming |
| Security | Support PSK authentication |
| Support static blacklist and whitelist | |
| Support WPA (TKIP), WPA2 (AES), and WPA-PSK data encryption | |
| Routing | Support static IP address, DHCP, PPPoE Dial Up |
| Management and maintenance | Support unified networking of all network equipment |
| Support local or remote management with Ruijie Cloud app | |
| Support local management with web | |
| Support remote management with Ruijie Cloud platform | |
| Platform management features | Automatic RF adjustment via the platform |
| Unified configuration via the platform | |
| Unified monitoring via the platform | |
