NZXT H5 Flow RGB (Black/White)

KEY SPECS

• Motherboard Support:Mini-ITX, Micro-ATX, ATX

• Enclosure Type:Mid-Tower

• Case Material (White):SGCC Steel, Ultra-clear Tempered Glass

• Case Material (Black):SGCC Steel, Dark Tinted Tempered Glass

DIMENSIONS

• Height (With Feet):464mm

• Height (Without Feet):448mm

• Width:227mm

• Depth:446mm

• Weight:7.36 kg

COMPATIBILITY & CLEARANCE

• Max CPU Cooler Clearance:Up to 165mm

• Max GPU Clearance:Up to 365mm

• Front Radiator Clearance:45mm

• Cable Management:Up to 23mm

• PSU Clearance:Up to 185mm

FRONT I/O PORTS

• USB 3.2 Gen 1 Type-A:1

• USB 3.2 Gen 2 Type-C:1

• Headset Audio Jack:1

EXPANSION SLOTS

• Standard:7

• Vertical :0

DRIVE BAYS

• 2.5":1+1

• 3.5":1

FAN SUPPORT

• Front:2 x 120mm / 2 x 140mm (2 x F Series RGB Core 140mm (Case Version) included)

• Top:2 x 120mm

• Rear:1 x F Series Quiet 120mm (Case Version) included

• Bottom:1 x F Series Quiet 120mm (Case Version) included

• Filters:All Air Intakes

RADIATOR SUPPORT

• Front:Up to 280mm

• Top:Up to 240mm

• Rear:Up to 120mm

FAN SPECS

• Model:F140 RGB Core Fan (Case Version)

• Speed:1200 ± 120 RPM

• Airflow:61.74 CFM

• Static Pressure:2.06mm-H2O

• Noise:29.05 dBA

• Fan Connector:3-pin

FAN SPECS

• Model:F120Q Airflow Fan (Case Version)

• Speed:1200 ± 120 RPM

• Airflow:62.18 CFM

• Static Pressure:1.05 mm-H2O

• Noise:25.1 dBA

• Fan Connector:3-pin
