CHIPSET | INTEL B760 |
CPU | Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors |
| LGA1700 |
MEMORY | 4x DDR5, Maximum Memory Capacity 192GB |
| Memory Support 7800+(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz |
| Max. overclocking frequency: |
| • 1DPC 1R Max speed up to 7800+ MHz |
| • 1DPC 2R Max speed up to 6600+ MHz |
| • 2DPC 1R Max speed up to 6400+ MHz |
| • 2DPC 2R Max speed up to 5600+ MHz |
| |
| Supports Dual-Channel mode |
| Supports non-ECC, un-buffered memory |
| Supports Intel® Extreme Memory Profile |
ONBOARD GRAPHICS | 1x HDMI™ |
| Support HDMITM 2.1 with HDR, maximum resolution of 4K 60Hz* |
| 1x DisplayPort |
| Support DP 1.4, maximum resolution of 4K 60Hz* |
| *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. |
SLOT | 1x PCI-E x16 slot |
| Supports x16/x4 |
| PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) |
| PCI_E2 Gen PCIe 3.0 supports up to x4 (From Chipset) |
STORAGE | 3x M.2 |
| M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices |
| M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices |
| M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280 devices |
| 4x SATA 6G |
RAID | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
USB | 4x USB 2.0 (Rear) |
| 4x USB 2.0 (Front) |
| 2x USB 3.2 Gen1 Type A (Front) |
| 3x USB 3.2 Gen2 Type A (Rear) |
| 1x USB 3.2 Gen2 Type C (Front) |
| 1x USB 3.2 Gen2x2 Type C (Rear) |
LAN | Realtek® 2.5Gbps LAN |
AUDIO | Realtek® ALC897 Codec |
| 7.1-Channel High Definition Audio |
| Supports S/PDIF output |
INTERNAL IO | 1x Power Connector(ATX_PWR) |
| 2x Power Connector(CPU_PWR) |
| 1x CPU Fan |
| 1x Pump Fan |
| 4x System Fan |
| 2x Front Panel (JFP) |
| 1x Chassis Intrusion (JCI) |
| 1x Front Audio (JAUD) |
| 1x Tuning Controller connector(JDASH) |
| 2x Addressable V2 RGB LED connector (JARGB_V2) |
| 1x RGB LED connector(JRGB) |
| 1x TPM pin header(Support TPM 2.0) |
| 4x USB 2.0 ports |
| 2x USB 3.2 Gen1 Type A ports |
| 1x USB 3.2 Gen2 Type C ports |
| 1x USB4 card connector (JTBT_U4_1, supports RTD3) |
LED FEATURE | 4x EZ Debug LED |
BACK PANEL PORTS | DisplayPort 1.4 |
| USB 3.2 Gen 2 10Gbps Type-A |
| 2.5G LAN Port |
| HD Audio Connectors |
| USB 2.0 |
| HDMI™ 2.1 Port |
| USB 3.2 Gen 2x2 20Gbps Type-C |
| USB 3.2 Gen 2 10Gbps Type-A |
| |
OPERATING SYSTEM | Support for Windows® 11 64-bit, Windows® 10 64-bit |
PCB INFO | mATX |
| 243.84mmx243.84mm |
