HYTE Y60 Mid Tower (ATX)

Tech Specs

Type

Dual Chamber Mid-Tower ATX Case

Volume

60L

Case Dimensions

456mm (L) x 285mm (W) x 462mm (H)

Case Weight

9.6 kg

Case in Box Dimensions

535mm (L) x 372mm (W )x 540mm (H)

Case in Box Weight

11.3 kg

Case Materials

Tempered Glass, Steel, ABS

Color

White/Black, Black/Black, Red/Black

Motherboard Support

EATX, ATX, mATX, ITX

Power Supply

ATX up to 235mm in length

Video Card Max Dimensions

375mm length, 75mm thick (60mm or less recommended for best cooling)

Fan Support (Side)

2x 120/140mm

Fan Support (Top)

3x 120mm

Fan Support (Rear)

1x 120mm (1x 120mm, 1300 RPM included)

Fan Support (Bottom)

2x 120mm/140mm (2x 120mm, 1300 RPM included)

Radiator Support (Side)

120, 140, 240, 280mm up to 150mm thick

Radiator Support (Top)

120, 240, 360mm up to 30mm thick

Radiator Support (Rear)

120mm

CPU Cooler Height

160mm*

Storage

2x 3.5" HDD or 4x 2.5" SSD

Expansion Slots

3 + 6 half-height

PCI Express Riser

4.0 x 16 (included)

Interfaces

Front USB 3.0

2

Front USB 3.2 Gen 2 Type-C

1

Audio/Mic Jack

1

Dust Filters

Bottom, Side, Top

RGB Lighting

None
