Interface |
LAN Port | 48x 10/100/1000Mbps Ethernet, RJ-45 6x 1000Mbps/10Gbps SFP+ |
Console Port | 1x RJ-45 |
Button | 1x Factory Reset Button |
Capacity |
Buffer Size | 16 Mbit |
Switching Capacity | 216 Gbps |
Forwarding Rate | 160.7 Mpps (64 bytes) |
MAC Address Table | 32k |
Jumbo Frame | Up to 12 KB |
L3 Routing Table | 12k static route + 12k prefix route |
Networking Standards |
IP Version | IPv4, IPv6 |
Ethernet Standards | 802.3 10Base-T 802.3u 100Base-T 802.3ab 1000Base-T IEEE802.3ae 10GBase-X 802.3x Flow Control 802.3 Auto-Negotiation 802.1q Tag-based VLAN 802.1p Class of Service 802.1d STP 802.1w RSTP 802.1s MSTP 802.3ad LACP 802.1ad QinQ 802.1x Port Access Control 802.1AB LLDP 802.3az EEE |
VLAN |
Max.Number of VLAN | 256 |
VLAN Type | 802.1q Tag-based MAC-based Protocol-Based Management VLAN Voice VLAN Surveillance VLAN |
802.1x Guest VLAN | |
Port Isolation | |
GVRP | |
Q-in-Q | Basic |
ONVIF Surveillance |
Discovery | |
Surveillance Topology | |
Real-Time Video Streaming | |
ONVIF Device Maintenance | Device Info, Reset Factory Default, Time Settings, Reboot |
QoS |
Number of QoS Queues | 8 |
Queue Scheduling | SPQ, WRR |
CoS (Class of Service) | 802.1p CoS, DSCP, CoS-DSCP, IP Precedence |
Rate Limit & Shaping | |
Security |
Access Control List | MAC, IPv4, IPv6 |
Storm Control | Broadcast, Unknown Multicast, Unknown Unicast |
DoS Defense | |
802.1x Port Access Control | |
IP Source Guard | |
IP Conflict Detection | |
IP Conflict Prevention | |
Loop Protection | |
Dynamic ARP Inspection | |
DHCP Snooping with Option 82 | |
Link Aggregation |
Max. Number of Group | 8 |
Max. Number of Member in Each Group | 8 |
Type | Static, LACP |
Traffic Load Balancing | MAC Address, IP/MAC Address |
Multicast |
IGMP Snooping | v2, v3 (BISS) |
IGMP Querier | |
MLD Snooping | v1, v2 (Basic) |
Max. Number of Multicast Group | 256 |
Group Throttling | |
Group Filtering | |
MVR (Multicast VLAN Registration) | |
Layer 3 Features |
Static Route | |
VLAN Route | |
DHCP Server | |
AAA |
Authentication Server | RADIUS, TACACS+ |
Port Authorization | |
Management Account | |
RADIUS Attribute Assignment | User Privilege, VLAN |
Accounting | |
Multiple Server | |
OpenFlow (xs model) |
Version | 1.3 |
Table Size | 1920 |
*The OpenFlow functionality is project-based and must be activated by DrayTek HQ. Please contact your Sales for further inquiries. |
Management |
Web Interface | HTTP, HTTPS |
Command Line Interface | Telnet, SSH v2 |
OpenVPN Client | Certificate-based authentication |
User Authentication | Local Database, RADIUS, TACACS+ |
sFlow | |
SNMP | v1, v2c, v3 |
Private MIB | |
RMON Group | 1, 2, 3, 9 |
LLDP | LLDP-MED, Media Endpoint Discovery Extension |
Mail Alert | Port Status, Port Speed, System Restart, IP Conflict |
Syslog | |
2-Level Admin Privilege | |
Multiple Admin Accounts | |
Managed by VigorRouter SWM | |
Managed by VigorConnect | |
Managed by VigorACS 2 | |
Config File Export/Import | |
Dual Image | |
SNTP (Simple Network Time Protocol) | |
Diagnostics Tools | Port Mirroring, Ping, Cable Test |
Physical |
19-inch Rack Mountable | Mouting Kit Included |
Power Input | AC 100-240V @ 2A |
Max. Power Consumption | 52 watts |
Dimension (mm) | 441(W) x 270(D) x 45(H) |
Weight | 3.97 kg (8 lb) |
Ventilation | Variable-speed Fan |
Operating Temperature | 0 to 50°C |
Storage Temperature | -20 to 70°C |
Operating Humidity | 10 to 90% non-condensing |
Storage Humidity | 5 to 90% non-condensing |
Certificate | |
